Upper Side Steer Spindle Steering Arm Steel
Steel Upper Steering Arm Hot Rod Side Steer

PART NUMBER: RSC-40317

1/2"-20 blind hole thread. Fits 1937-1948 Ford spindles. Made for side steer applications. Accepts 5/8" or 11/16" Ford tie rod ends. Tapered 7 degrees in one direction. Reversible to change taper direction, or drill to 5/8" to accept heim joint. SOLD EACH
: $89.99

Qty:

Overview

FEATURES:

For Use With 1928-1948 Ford Spindles

Spindle Mounting Center to Center Width: 3.300"
Mounting Flange to Tie Rod Center: 6 1/4"
Tie Rod End Taper Angle: 7 Degree
Thread Size: 1/2" - 20

Manufactured from investment cast, 1045 steel, this steering arm can be flipped over to allow the tie rod end to be inserted from the top or bottom. The long ratio is engineered to provide a smoother turning radius and a more comfortable ride than other options. This item is also available in stainless steel on this store. Search for Side Steer Steering Arm in the search box to learn more.


WHAT'S INCLUDED:
1 (ONE)
Plain Steel Upper Steering Arm


NOTES & TIPS:

Taper can be drilled out with a 5/8" drill bit to accept 5/8" heim joint or rod end.
